You can depend on Fluke tools to keep your world up and running.

Fluke® tools perform like champions in the most challenging utility-scale mining  environments. You can depend on Fluke tools to keep your world up and running.

Motor Drive Analyser

Fluke MDA-550 Series III

Motor Drive Analyser

The Fluke MDA-550 Motor Drive Analyser is the ideal portable analysis test tool that can help you safely locate and troubleshoot problems on motor-drive systems. In both surface and underground mine sites, there are hundreds of motor driven assets that benefit from the speed or torque control offered by variable speed AC drives. The Fluke MDA-550 helps you easily diagnose problems and keep these VSD systems up and running in peak condition.

  • Guided testing with graphical step-by-step connection diagrams

  • Preset measurement profiles reduce setup complexity

  • Use built-in report writing capabilities to easily produce as-found and as-left troubleshooting reports

Download Datasheet
Download Datasheet
Motor Drive Input
Phase-phase
V-A-Hz
Phase-ground
V pk, Vmax, Vmin, V pk-to-pk, Crest factor
Voltage unbalance
V ac+dc Unbalance,V pk-to-pk
Current unbalance
V ac+dc Unbalance, A pk-to-pk
Motor Drive DC Bus
DC
V dc,V pk-to-pk, V peak max
Ripple
V ac,V pk-to-pk,Hz
Motor Drive Output
Voltage and current (filtered)
V-A-Hz, V PWM, V/Hz
Voltage unbalance
V PWM Unbalance, V pk-to-pk
Current unbalance
A ac+dc Unbalance, A pk-to-pk
Voltage modulation
Phase-phase, Phase-ground, Phase-DC +, Phase-DC -;
V PWM,V pk-to-pk, Hz, V/Hz, Delta V/s, Risetime peak,Overshoot
Motor Input
Voltage and current (filtered)
V-A-Hz, V PWM,V pk,A ac+dc, A pk,V/Hz, Crest factor
Voltage unbalance
V PWM Unbalance, V pk-to-pk
Current unbalance
A ac+dc Unbalance, A pk-to-pk
Voltage modulation
Phase-phase, Phase-ground, Vpwm, Vpk-to-pk, Hz, V/Hz, Delta V/s,Risetime peak,Overshoot
Motor shaft
Shaft voltage events: V pk-to-pk, Delta V, Rise/fall time, Delta V/s, Events/s
Motor drive input, output and motor input
Voltage and Current Harmonics, V and A fundamental, Hz fundamental,% THD,% THD/TDD
